PRO Z 560 L KW
PRO Z 500 L SERIES
Item#:
53TIHJTV050
From
$ 18,499.00
MSRP
PRO Z 560 L KW
PRO Z 500 L SERIES
Item#:
53TIHJTV050
From
$ 18,499.00
MSRP
- 27 HP Kawasaki FX850v (852cc) engine and 12cc Parker HTJ transmission
- 60” triple-7-gauge fabricated steel cutting deck with top, bottom and side reinforcements
- 3-year limited commercial warranty (no hour limitations) and 5 year / 1,750 hour limited deck construction warranty
You're shopping available inventory from
Attachments & Accessories
PRO Z 560 L KW Features
Specs & Maintenance
Engine
- Engine Brand Kawasaki®
- Engine Model FX Series
- Engine Model Number 850V
- Engine Displacement 852cc
- Engine Output 27HP
- Fuel Tank Capacity Dual 7.45 gal. US (28.2 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 15 amp regulated
- Fuel Gauge Dial
- Choke Separate Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Carburetor
Drive System
- Transmission Parker HTJ Series 12cc pump / 260cc wheel motor
- Forward Speed 10 mph / 16 km/h
- Reverse Speed 5 mph / 8km/h
Cutting Deck
- Deck Cutting Width 60 in
- Deck Material fabricated 7ga. (.187”) steel shell
- Deck Engagement (PTO) electronic fingertip engagement pto
- Deck Construction 7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge
- Blade(s) 3 high-lift Marbain® blades / 18,500 fpm (approx.)
- Cutting Height Range 1” to 5” in 1/4” increments
- Anti-Scalping 2 front deck gauge wheels
- Deck Positions Foot pedal with spring assist 16 Positions
Chassis
- Frame Fully welded, full-length 3/8 x 5" laser cut steel / integrated tie-down slots
- Front Axle 2" x 3" solid axle tube and 1/2" thick steel front yokes
- ROPS 2" x 2" quick-latch tool-less foldable 3 position
- Bumper 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
Controls
- Cruise Control NA
- Steering Control High Performance & Speed Control
Comfort
- Seat Type Cushion
- Armrests Standard
- Seat Suspension High-back dial suspension with EVC, with seatbelt
- Seat Adjustment Angle back adjust
Wheels
- Rear Tires 24"x12"-12"
- Front Tires 13"x6.5"-6" Std Smooth Carlisle-Air Filled
- Tire Tread Turf Tread
Dimensions
- Dimensions L/W/H 84" L x 62" W x 50" H
- Weight (approx.) 1324 lbs.
Additional Specifications
- Hour Meter Crew Boss
- Discharge Chute High-density, impact-resistant rubber
- Cup Holder Intergrated into Side Pod
- Model Number 53TIHJTV050
Warranty
- Warranty 3 year / no hour limit commercial warranty and 5 year / 1,750 hour limited deck construction warranty
- Deck Shell Warranty 5 year / 1,750 hour limited deck construction warranty
- Commercial Warranty 3 year / no hour limit commercial warranty
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Model | Manual | Form Number | |
|---|---|---|---|
| 53TIHJTV050 | MANL:OPER:ENGL:PRO Z XXXL | ||
| MANL:OPER:ENGL:PRO Z XXXL | 769-17796 | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-17796A | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-17796B | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-17796C | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-17796D | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-17796E | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-26265 | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-26265A | Download | |
| MANL:OPER:ENGL:PRO Z XXXL | 769-26788 | Download | |
| MANL:OPER:ENGL:PRO Z XXXL (18) | 769-12347 | Download | |
| MANL:OPER:FRENCH:PRO Z XXXL | 769-17796_FR | Download | |
| SHEET:SUP:BILING:EPA:EVP:06301 | 769-15171 | Download | |
| SHEET:SUP:BILING:EPA:EVP:18-19 | 769-17171 | Download | |
| SHEET:SUP:BILING:EPA:EVP:18-19 | 769-23590 | Download | |
| SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download | |
| SHEET:SUP:BILING:EPA:EVP:21-22 | 769-26272 | Download | |
| SHEET:SUP:BILING:EPA:EVP:22-23 | 769-26607 | Download | |
| SHEET:SUP:Warranty_Addendum_In | 769-26830 | Download |
Product Reviews
Rated 2 out of
5
by
needens from
Just okay
This was a great mower for a while. The build is solid and it is capable of handling slopes without issue. Now with around 150 hours on it the left hand transmission is failing. Thankfully it didn't fail completely until I got it back up the hill and to the house. This doesn't speak well for longevity of major components are failing after this amount of run time especially on an expensive commercial mower. Disappointed. We'll see if it's covered under warranty.
Date published: 2021-05-03
Rated 5 out of
5
by
RLT67 from
Excellent Mower!
I bought this model 3 months ago for a new house we purchased with 4.5+ acres of lawn to mow, some flat, some slopes, some obstacles (like trees and bushes). It has performed beautifully! Cuts the grass perfectly and I can get the entire lawn done in about 3 - 3.5 hours. I can also get two complete mows out of one fill-up (2 full tanks). It's comfortable and well built. It maneuvers around trees and bushes pretty well for a big mower. This is my first zero turn so it took me about 3 mows to get really used to it and learn how to really turn and maneuver, but now it's second nature. We have some pretty thick grass at the lower parts of our property too, where water settles and keeps the grass greenest and longest. We're talking grass that's around 7-10 inches high by the time I can get to it after the ground dries enough. If I run through that slowly the tractor doesn't complain and cuts the grass the same uniform length as the rest of the yard - a professional look all the way around - I typically run it at the 4" deck level. Would highly recommend it for anyone with some acreage who doesn't want to spend all their free time mowing grass!!!
Date published: 2019-09-23
Rated 5 out of
5
by
GERod from
Great Mower
Very happy with this purchase. I have 4-5 acres to mow and can get it done in 3 hours. The speed and comfort of the machine is incredible!
Date published: 2019-06-05
Rated 4 out of
5
by
davesm from
Very heavy duty mower for the money
[This review was collected as part of a promotion.] I have 216 hours on the mower with only one repair. I cracked a flange on a blade spindle housing. I feel that the housing should be ductile iron, especially for the service part cost.
Date published: 2021-11-30
Rated 1 out of
5
by
Reddog from
Junk
I was mowing Saturday all of a sudden started making grinding sound right rear tire fell off axle threads are completely stripped wheel is ruined it just turned 10 hrs on mower.Waiting on dealer to come pick it up! Hopefully will get a new one or my money back!
Date published: 2021-03-22
Rated 4 out of
5
by
Paully78 from
Like the over cut of blades. No left grass not cut
[This review was collected as part of a promotion.] Tried out the mower last week and it mowed really well. Had lots of room for work area. Doesn’t feel cramped.
Date published: 2020-03-27
Rated 5 out of
5
by
RLT67 from
Excellent Mower!
[This review was collected as part of a promotion.] I bought this model 3 months ago for a new home we purchased with 4.5+ of lawn to mow. Some slopes, some flat, some obstacles (e.g. trees and bushes). It has performed beautifully. It has an ultra-comfortable ride and plenty of power. I can get my entire lawn done in about 3.5 - 4 hours and I can get two complete mows out of a fill-up (both tanks full), so there's no stopping to fill-up in the middle of mowing. We have some pretty long grass at the lower parts of our property where the water settles that keeps it greenest and longest. By the time I can get in there to mow it, after the ground dries enough, the grass is sometimes 7-10 inches long. I run the deck at 4 inches and if I run through that grass slowly the tractor doesn't complain one bit and it looks as professional as the rest of the lawn. It maneuvers around our trees and other obstacles without any issues for a big tractor. Once you get the hang of it it's pretty easy to get into even the tightest of places. This is my first zero turn and it took me about 3 mows get really used to the tractor and be able to make so pro turns and edging, but now it's second nature. I can't get over how smooth the ride is, we have some rough spots on our lawn too, and I'm thankful for the seat that's on this thing - it's like riding on air! I've run it through some pretty thick grass and it just hums along. I've had other riding tractors that would've stalled out or at least sounded like they were under stress, not this thing - it has POWER! I highly recommend this to anyone with some acreage who doesn't want to spend all their free time mowing grass - enjoy your lawn!!!
Date published: 2019-09-23
