PRO Z 972S DW
PRO Z 900 S SERIES
Item#:
53TIHMUY050
MSRP
PRO Z 972S DW
PRO Z 900 S SERIES
Item#:
53TIHMUY050
MSRP
One of the best zero-turn mowers for slopes on the market with steering wheel control. Ample horsepower and dual-wheel traction mean this slope mower can handle up to a 46% grade. Tackle inclines confidently with this zero-turn slope mower. It cuts straight lines on slopes up to 25 degrees.
- A powerful slope mower with 35 HP Kawasaki FX1000v (999cc) engine and 16cc Parker HTG transmission
- 72” triple-7-gauge fabricated steel cutting deck with top, bottom and side reinforcements
- 3-year limited commercial warranty (no hour limitations) and 5 year / 1,750 hour limited deck construction warranty
- Dual rear wheels and weighted front rims give this steep slope mower traction on up to a 46% grade. 12-volt outlet kit and electronic power deck lift included
You're shopping available inventory from
PRO Z 972S DW Features
Specs & Maintenance
Engine
- Engine Brand 35 HP Kawasaki® FX1000v Series V-Twin OHV, 999cc
- Engine Model FX Series
- Engine Model Number 1000V
- Engine Displacement 999cc
- Engine Output 35HP
- Fuel Tank Capacity Dual 7.5 US gal. (28.4 L) / 15 US gal. total (56.8 L)
- Cylinders 2/cast-iron sleeve
- Engine Start Ignition Key
- Engine Oil Capacity 2 US qt. / 1.90 L
- Lubrication Full-pressure with spin-on oil filter
- Charging System 15 amp. regulated
- Fuel Gauge Standard (sight window in tank)
- Choke Separate Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Carburetor
Battery
- Battery 12V / 300 cold crank amps
Drive System
- Transmission Parker HTG 16cc pump / 310cc wheel motor
- Forward Speed 12 mph (19.3 km/h)
- Reverse Speed 6 mph (9.6 km/h)
Cutting Deck
- Deck Cutting Width 72 in
- Deck Wash Patented SmartJet™ high-pressure deck washing system
- Deck Material fabricated 7ga. (.187”) steel shell
- Deck Engagement (PTO) electronic fingertip engagement pto
- Deck Construction Fabricated slope nose -10 gauge shell, floating, fabricated w/7 gauge reinforced plate
- Spindle Construction 8" sealed cast aluminum housing (maintenance-free)
- Blade(s) Triple-blade / High-lift blade (standard) Marbain Blade
- Deck Lift Electronic power deck lift system (included)
- Cutting Height Range 1" - 5" (in .25" increments)
- Anti-Scalping 4 front heavy-duty, greasable, 2 nose rollers, rear striping roller
- Deck Positions Foot pedal with spring assist 16 Positions
Chassis
- Frame Heavy-duty rail frame 3/8" x 5" laser cut steel w/tie-down slots
- Front Axle Heavy-duty 2" x 3" fabricated steel, greasable tapered roller bearings
- ROPS 2"X2" foldable 3 position low profile clearance
- Bumper 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
- Rear Tow Hitch Standard
- Yokes 1/2" thick steel front yokes
Controls
- Cruise Control NA
- Brakes Hand-operated lever with integrated hydro pump release lever
- Steering Control Steering wheel with comfort grip and quick adjust tilt steering column
Comfort
- Seat Type High back adjustable dial suspension and elasticity vibration control (EVC) comfort seat , padded arm rests ISO mounted base (lateral suspension) angle back adjust and lumbar support and seat belt
Wheels
- Rear Tires Dual TERRA TRAC Tread 25" x 9" – 12" (18” trac width)
- Front Tires 16" x 6.5" - 8" Turf (with weighted rim)
Dimensions
- Dimensions L/W/H 88" L x 85" W x 49" H
- Weight (approx.) 1,770 lbs
Additional Specifications
- Hour Meter Crew Boss
- Discharge Chute High-density, impact-resistant rubber
- Cup Holder Standard
- Model Number 53TIHMUY050
Warranty
- Deck Shell Warranty 5 year / 1,750 hour limited deck construction warranty
- Commercial Warranty 3 year / no hour limit commercial warranty
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Model | Manual | Form Number | |
|---|---|---|---|
| 53TIHMUY050 | MANL:OPER:ENGL:PRO Z DUALLY | ||
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490 | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490A | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490B | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490C | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490D | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490E | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-18490F | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-26332 | Download | |
| MANL:OPER:ENGL:PRO Z DUALLY | 769-26681 | Download | |
| MANL:OPER:ENGL:PRO Z XXXS (18) | 769-12364A | Download | |
| MANL:OPER:FRENCH:PRO Z DUALLY | 769-18490_FR | Download | |
| SHEET:SUP:BILING:EPA:EVP:06301 | 769-15171 | Download | |
| SHEET:SUP:BILING:EPA:EVP:18-19 | 769-17171 | Download | |
| SHEET:SUP:BILING:EPA:EVP:18-19 | 769-23590 | Download | |
| SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download | |
| SHEET:SUP:BILING:EPA:EVP:21-22 | 769-26272 | Download | |
| SHEET:SUP:BILING:EPA:EVP:22-23 | 769-26607 | Download | |
| SHEET:SUP:Warranty_Addendum_In | 769-26830 | Download | |
| SHEET:SUPPLEMENT:BATTERY:PROZS | 769-26445 | Download |
