PRO Z 154 S EFI
PRO Z 100 S SERIES
Item#:
53TWEFJA050
$ 11,299.00
PRO Z 154 S EFI
PRO Z 100 S SERIES
Item#:
53TWEFJA050
$ 11,299.00
- Commercial-grade 27 HP Kohler EFI engine
- 54-inch 10-gauge steel commercial deck with top, bottom and side reinforcements for added durability
- 12cc commercial-grade transmission ensures optimal blade tip speed and superior quality of cut at speeds up to 9.5 mph
Specs & Maintenance
Engine
- Engine Brand Kohler®
- Engine Model Confidant EFI
- Engine Model Number EZT750
- Engine Displacement 747cc
- Engine Output 27HP
- Fuel Tank Capacity Dual 3.5 gal. US (13.25 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 15 amp regulated
- Fuel Gauge No
- Choke Auto-Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Electronic Fuel Injection (EFI)
Drive System
- Transmission 12cc Hydro-Gear® ZT 3400 with charge pumps
- Forward Speed 9.5 mph / 15 km/h
- Reverse Speed 4.5 mph / 7 km/h
Cutting Deck
- Deck Cutting Width 54 in
- Deck Engagement (PTO) electronic fingertip engagement pto
- Deck Construction Floating, fabricated 10ga. (.135”) steel shell (e-coated)
- Spindle Construction 5" sealed cast aluminum housing (maintenance-free)
- Blade(s) 3 high-lift Marbain® blades / 18,500 fpm (approx.)
- Cutting Height Range 1” to 5” in 1/4” increments
- Anti-Scalping 4 Front HD w/ Bushings & Grease Zerk
- Deck Positions Hand Lever / 15 position / spring assist
Warranty
- Warranty 4-year/500-hour limited residential warranty
- Commercial Warranty 2-year limited commercial warranty (no hour limitations)
Chassis
- Frame Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements
- Front Axle 2" x 3" solid steel
- ROPS 2" x 2" quick-latch tool-less foldable 3 position
- Bumper 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
- Yokes 3/8" thick steel with sealed ball bearing front yokes
Controls
- Cruise Control Standard - Foot operated pedal engagement
- Brakes Foot-operated pedal
- Steering Control High Performance Steering Wheel with Foot-pedal Control
Comfort
- Seat Type Cushion with seat belt
- Armrests adjustable arm rests
- Seat Suspension High-back suspension
Wheels
- Rear Tires 23"x 10.5"-12"
- Front Tires 13"x6.5"-6" turf
- Tire Tread Turf Master
Dimensions
- Dimensions L/W/H 80" L x 56" W x 48" H
- Weight (approx.) 1000 lbs.
Additional Specifications
- Hour Meter Basic Hour Meter (no tach)
- Discharge Chute High-density, impact-resistant rubber
- Cup Holder Intergrated into Side Pod
- Model Number 53TWEFJA050
Disclaimer
- Specifications Disclaimer Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Model | Manual | Form Number | |
---|---|---|---|
53TWEFJA050 | MANL:OPER:ENGL:CC PRO Z 100 | ||
MANL:OPER:ENGL:CC PRO Z 100 | 769-12380 | Download | |
MANL:OPER:ENGL:CC PRO Z 100 S | 769-24910 | Download | |
MANL:OPER:ENGL:CC PRO Z 100 S | 769-24910A | Download | |
MANL:OPER:FRENCH ONLY:CC PRO Z 100 | 769-12380_FR | Download | |
MANL:OPER:FRENCH:CC PRO Z 100 S | 769-24910A_FR | Download | |
SHEET:SUP:BILING:EPA:EVP:06301 | 769-15171 | Download | |
SHEET:SUP:BILING:EPA:EVP:18-19 | 769-17171 | Download | |
SHEET:SUP:BILING:EPA:EVP:18-19 | 769-23590 | Download | |
SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download |
