PRO Z 154 S EFI
PRO Z 100 S SERIES
Item#:
53TWEFJA050
$ 11,299.00
PRO Z 154 S EFI
PRO Z 100 S SERIES
Item#:
53TWEFJA050
$ 11,299.00
- Commercial-grade 27 HP Kohler EFI engine
- 54-inch 10-gauge steel commercial deck with top, bottom and side reinforcements for added durability
- 12cc commercial-grade transmission ensures optimal blade tip speed and superior quality of cut at speeds up to 9.5 mph
Specs & Maintenance
Engine
- Engine Brand Kohler®
- Engine Model Confidant EFI
- Engine Model Number EZT750
- Engine Displacement 747cc
- Engine Output 27HP
- Fuel Tank Capacity Dual 3.5 gal. US (13.25 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 15 amp regulated
- Fuel Gauge No
- Choke Auto-Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Electronic Fuel Injection (EFI)
Drive System
- Transmission 12cc Hydro-Gear® ZT 3400 with charge pumps
- Forward Speed 9.5 mph / 15 km/h
- Reverse Speed 4.5 mph / 7 km/h
Cutting Deck
- Deck Cutting Width 54 in
- Deck Engagement (PTO) electronic fingertip engagement pto
- Deck Construction Floating, fabricated 10ga. (.135”) steel shell (e-coated)
- Spindle Construction 5" sealed cast aluminum housing (maintenance-free)
- Blade(s) 3 high-lift Marbain® blades / 18,500 fpm (approx.)
- Cutting Height Range 1” to 5” in 1/4” increments
- Anti-Scalping 4 Front HD w/ Bushings & Grease Zerk
- Deck Positions Hand Lever / 15 position / spring assist
Warranty
- Warranty 4-year/500-hour limited residential warranty
- Commercial Warranty 2-year limited commercial warranty (no hour limitations)
Chassis
- Frame Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements
- Front Axle 2" x 3" solid steel
- ROPS 2" x 2" quick-latch tool-less foldable 3 position
- Bumper 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
- Yokes 3/8" thick steel with sealed ball bearing front yokes
Controls
- Cruise Control Standard - Foot operated pedal engagement
- Brakes Foot-operated pedal
- Steering Control High Performance Steering Wheel with Foot-pedal Control
Comfort
- Seat Type Cushion with seat belt
- Armrests adjustable arm rests
- Seat Suspension High-back suspension
Wheels
- Rear Tires 23"x 10.5"-12"
- Front Tires 13"x6.5"-6" turf
- Tire Tread Turf Master
Dimensions
- Dimensions L/W/H 80" L x 56" W x 48" H
- Weight (approx.) 1000 lbs.
Additional Specifications
- Hour Meter Basic Hour Meter (no tach)
- Discharge Chute High-density, impact-resistant rubber
- Cup Holder Intergrated into Side Pod
- Model Number 53TWEFJA050
Disclaimer
- Specifications Disclaimer Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Model | Manual | Form Number | |
|---|---|---|---|
| 53TWEFJA050 | MANL:OPER:ENGL:CC PRO Z 100 | ||
| MANL:OPER:ENGL:CC PRO Z 100 | 769-12380 | Download | |
| MANL:OPER:ENGL:CC PRO Z 100 S | 769-24910 | Download | |
| MANL:OPER:ENGL:CC PRO Z 100 S | 769-24910A | Download | |
| MANL:OPER:FRENCH ONLY:CC PRO Z 100 | 769-12380_FR | Download | |
| MANL:OPER:FRENCH:CC PRO Z 100 S | 769-24910A_FR | Download | |
| SHEET:SUP:BILING:EPA:EVP:06301 | 769-15171 | Download | |
| SHEET:SUP:BILING:EPA:EVP:18-19 | 769-17171 | Download | |
| SHEET:SUP:BILING:EPA:EVP:18-19 | 769-23590 | Download | |
| SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download |
Product Reviews
Rated 5 out of
5
by
Pat6156 from
The beast.
I recently purchased a Z154 s and I would like to tell you how nice it is however I haven't had much seat time. The day of the first cutting I backed it out the shop and then my son said he wanted to try it out. A acre and a half later he gets off and my wife hops on to do the front. A little over a acre and dogging around a bunch of tree and around the pound she brings it back and tells me we should of gotten one of these a long time ago. Its build tough handles better than expected. Pond berms are nothing for this machine. This a first review I intend to update posts after awhile.
Date published: 2018-09-20
Rated 5 out of
5
by
BryanG from
Very Comfortable!
[This review was collected as part of a promotion.] I moved up from the Cub Cadet ZForce48S to the ProZ154SEFI. Owned the previous model for 7 years and it did a great job. So far, I have 15 hours on the new unit and its working out great. The upgraded seat is really comfortable and makes mowing much easier on my back. The new Cub is super easy to operate with simple controls that are easy to reach. The cut quality is outstanding. Currently running a set of mulching blades which helps with thick grass. Will switch over to the standard blades to try them out as well. The mulch blades are also helpful in the fall for leaf clean up. Very happy with purchase.
Date published: 2020-06-09
Rated 5 out of
5
by
CJ R from
Cub Perfection
Mowed my property twice now and this thing is just impressive. I have a pretty intense slope in my yard and this tractor is unaffected by it. Mowed with a Garden Tractor before, orange in color, that had limited slip and there is just no comparison between the two. Not even close. The ProZ mows even, doesn't scalp, has plenty power, and can mow slopes with confidence. I am absolutely thrilled with this mower.
Date published: 2019-07-26
Rated 5 out of
5
by
HapDog from
This is the total package
I have had my Pro Z 154S for about 3 weeks now. All I can say is that it is the real deal. My yard is 4 acres and I can mow it in about a hour. It used to take me a 1 and half with my old cub. The thing cruises along. I also have a 40 degree bank I have to cut. It has no issues and it feels like I am driving a car instead of a mower. Engine is strong. The cut is great and zero turn is awesome.
Date published: 2016-05-23
Rated 5 out of
5
by
RonF from
Amazing
This is a very preliminary review. In fact, the mower was delivered yesterday and it is now into its second hour of mowing. Bought this mower for my wife because she is mowing 4+ acres here at my office and we mow about 20 acres at home. She did not want any part of a lap bar mower and she would not even give my joy stick mower an honest attempt But she test drove this Pro Z 154S and it was like love at first sight. I sit her now and watch out the window at her mowing and you would think she was driving a go cart. This is an excellent machine and so far exceeds our expectations. It promises to be a very durable and reliable mower. Solidly designed and built. BTW - she was previously mowing the yard here with a garden tractor which was taking over 4 hours to complete the job. With this mower, her cutting time will be slightly over an hour. How sweet is that?
Date published: 2018-06-05
Rated 5 out of
5
by
NANANA from
My wife loves it!
We have mowed our three acres two times. It used to take three hours. My wife does most of the riding while I trim. We mowed in one and a half hours. My wife gets off of the Cub Cadet Pro Z and is not even tired. We are glad we moved up to the PRO Z. The Cub does our hills very well. Cutting around trees is a breeze.
Date published: 2020-04-12
Rated 5 out of
5
by
gggreen from
Works Great
Just purchased the ProZ100 from B&B repair in Webster City,Iowa. It was delivered as promised set up and running perfectly! Seems to be a rugged well built machine. Love the steering wheel and overall performance. Thanks a bunch!
Date published: 2017-05-27
Rated 5 out of
5
by
MonsterMowerRocks from
Could cut grass ALL day.
Bought over a month ago. Best money spent. We have a fairly steep ditch line and I wasn’t sure how it would do, it makes short work of it. My neighbor hadn’t cut his grass yet this year(July) til I showed up. 2 1/2 acres of 3’ grass in 2 1/2 hours now look like a golf course.
Date published: 2019-08-18
